Corrosion Characteristics and Module Reliability Assessment of Floating Photovoltaic Systems in offshore Environments

Myenggil Gang; Seong Dae Kim; Alex Lim; Hyunsik Jo; Jieun Lee; Chang-Sub Won

doi:10.21218/CPR.2026.14.3.112

All Issue

2026 Vol.14, Issue 3 Preview Page Next Page

Corrosion Characteristics and Module Reliability Assessment of Floating Photovoltaic Systems in offshore Environments 해상 환경 부유식 태양광 시스템의 부식 특성 및 모듈 신뢰성 평가

30 September 2026. pp. 112-119

PDF XML

Abstract

This study presents a case analysis of corrosion effects and photovoltaic module reliability in floating photovoltaic (FPV) systems installed in harsh offshore environments in South Korea. In collaboration with K-Water, a marine FPV test-bed was installed in 2021 at Saemangeum seawater lake to investigate the durability and operational stability of floating solar power systems under corrosive and mechanically demanding conditions. The environmental conditions included typhoon-induced wave heights of up to 2 m and wind speeds reaching 25 m/s. The modular raft-type floating system had a capacity of 100 kW and incorporated approximately 240 shingled 420 W photovoltaic modules. The study focused on both the atmospheric corrosion behavior of FPV structural materials and the occurrence of cell cracks in floating photovoltaic modules. To evaluate corrosion resistance, exposure tests were conducted on PosMAC (Zn-3%Mg-2.5%Al ternary alloy-coated steel), stainless steel, and aluminum in accordance with ISO 9223 and ISO 9226 standards. Corrosion grades and corrosion rates were assessed through periodic measurements conducted every three months over a one-year exposure period. Specimen holder units were designed to minimize specimen occlusion and prevent galvanic interference. After the exposure tests, corrosion products were removed using chemical cleaning procedures according to the metal type, and corrosion rates were determined by weight-loss measurements. In parallel, Electroluminescence (EL) testing was conducted twice during operation to analyze the generation and propagation of solar cell cracks. The results showed that some cracks remained stable in localized regions of the modules, whereas others progressively developed under mechanical stress and environmental loading conditions. The findings provide important insights into the corrosion characteristics of FPV structural materials and the mechanical durability of photovoltaic modules in marine environments.

Keywords

Photovoltaic

Floating Photovoltaic System

Renewable Envergy

Maintenance

Corrosion test

Off-shore

Electroluminescence

References

N. Lee, U. Grunwald, E. Rosenlieb, H. Mirletz, A. Aznar, R. Spencer, S. Cox, Hybrid floating solar photovoltaics-hydropower systems: Benefits and global assessment of technical potential. Renew. Energy 162, 1415-1427 (2020).

10.1016/j.renene.2020.08.080

J. Farfan, C. Breyer, Combining floating solar photovoltaic power plants and hydropower reservoirs: a virtual battery of great global potential. Energy Procedia 155, 403-411 (2018).

10.1016/j.egypro.2018.11.038

J. Kester, J. Liu, A. Binani, Carbon footprint analysis of floating PV systems. Power 60, 87 (2024).

10.69766/JGAZ9626

A. Goswami, Harnessing the promise of floating solar photovoltaics in sustainable energy revolution. Cambridge Prisms: Energy Transitions 1, e1 (2025).

10.1017/etr.2025.1

G. Chowdhury, M. Haggag, J. Poortmans, How cool is floating PV? A state-of-the-art review of floating PV's potential gain and computational fluid dynamics modeling to find its root cause. EPJ Photovolt 14, 24 (2023).

10.1051/epjpv/2023015

C. M. Lo, L. H. Tsai, H. H. La, W. T. Wu, M. D. Lin, A study on the metallic corrosion characteristics under atmospheric environment in Taiwan: Taking Taichung Harbor as an example. Mater. Corros. 69(2), 251-265 (2018).

10.1002/maco.201709647

A. Castañeda, C. Valdés, F. Corvo, Atmospheric corrosion study in a harbor located in a tropical island. Mater. Crros. 69(10) 1462-1477 (2018).

10.1002/maco.201810161

F. Corvo, T. Pérez, L. R. Dzib, Y. Martín, A. Castañeda, E. González, J. Pérez, Outdoor–indoor corrosion of metals in tropical coastal atmospheres. Corros. Sci. 50, 220-230 (2008).

10.1016/j.corsci.2007.06.011

M. Morcillo, B. Chico, J. Alcantara, I. Diaz, J. Simancas, D. De la Fuente, Atmospheric corrosion of mild steel in chloride-rich environments. Questions to be answered. Mater. Corros. 66(9), 882-892 (2015).

10.1002/maco.201407940

ISO 9223, Corrosion of metals and alloys. Corrosivity of atmospheres. Classification, determination, and estimation (2012).

ISO 9226, corrosion of metals and alloys. Corrosivity of atmospheres. Determination of corrosion rate of standard specimens for the evaluation of corrosivity (2012).

ISO 8407. Corrosion of metals and alloys. Corrosivity of atmospheres. Removal of corrosion products from corrosion test specimens (2021).

ISO 9224, corrosion of metals and alloys. Corrosivity of atmospheres. Guiding Values for the corrosivity categories (2012).
